• Age: 2021
• Max size: 760 x 1060 mm
• Impress count: 8,4 mio
• Machine type: Laminating machines
• Condition: perfect
• Availability: at once

The manufacturer is the Italian company Ecosystem Costruzioni Meccaniche.
TECHNICAL SPECIFICATIONS:
Max. sheet size (W x L): 760 x 1060 mm;
Min. sheet size: 210 x 250 mm;
Max. mechanical speed: 60 m/min*;
Feeder output: up to 10,000 sheets/hour*;
Paper weight: 115 – 600 gsm;
Max. film width: 750 mm;
Max. film roll diameter: 350 mm;
Film core diameter: 3”;
Working height (including pallet): 900 mm;
Max. pile weight (including pallet): 750 kg;
*Production speed depends on the materials used and the operator's skill.

POWER AND INSTALLATION REQUIREMENTS:
Electrical supply: 400 V, 3-phase + PE, 50 Hz;
Power consumption: 31 kW;
Compressed air: 700–900 nl/min at 8 bar;
(Air compressor not included in the delivery.);

MACHINE COMPONENTS:
Cutting system: Standard and Hot knife with Scatec laser correction, ensuring perfect film cutting even on difficult substrates (metallized PET, nylon).
Automatic sheet feeder with suction table, electronically controlled feeding and timing (PIAB system);
Film unwinder with inline trimming system;
Laminating unit with chrome-plated heated calender (water-circulation heating) and rubber pressure roller;
External water heater unit with pressure system, pipework, and shut-off valves for the laminating calender;
Sheet separation group with smoothing system, film perforation via abrasive wheel, and separation rollers;
Hot knife system with Scatec laser correction – suitable for metallized PET, nylon, embossed and special films;
Automatic stacker;
Touchscreen control panel;
Remote assistance system via Ethernet (client provides ADSL connection);
CE-compliant operation manual;
Spare pressure roller with bearings and dedicated transport cart.

In excellent condition.
Can be seen in production.

Price on request
