Technical Specifications:
Max Paper Size: 720 x 1020 mm;
Min Paper Size (Straight): 280 x 420 mm;
Min Paper Size (Perfecting): 400 x 420 mm;
Max Printing Area: 700 x 1020 mm;
Maximum Speed: 12000 sheets per hour (sh/h);
Stock Thickness Range: 0.03 mm to 0.6 mm;
Dimensions: Length: Approx. 9.87 x Width: 2.99 x Height: 2.17 (m);
Weight: Approx. 31,910 kg – 32,360 kg;
Key Equipment & Features:
Perfecting Configuration: Built-in perfector allowing 5/0 or 1/4 convertible perfecting modes;
Dampening & Cooling: Alcohol dampening system with automatic control via Technotrans;
Control Console: CPC 1.02 remote control system for ink and register adjustments;
Delivery & Drying: High pile delivery system equipped with an infrared (IR) dryer and powder sprayer (Grafix Exactomat);
In production.
